Avlink VGA-E8 - Manual (Page 4)

Features
ƒ Through the VGA Extender, you can use one PC to display identical image and extension of
VGA signal up to 180/300 meter on monitors.
ƒ Equalization length is adjustable.
ƒ VGA signal gain is adjustable.
Specifications
Function VGA-L VGA-R VGA-L-PRO VGA-R-PRO
VGA In/Out Connector HD-15 Female x 1
RJ-45 Connector 1
Max. Resolution 2048x1536 60Hz
Cable Distance 180 m (Max.) 300 m (Max.)
Power Adapter (Min.) DC 12V 600mA
Housing Metal
Weight 135g 140g 135g 140g
Dimensions (LxWxH) mm 92x34x22 92x34x22
Function VGA-L + VGA- L + -PRO VGA-E2 VGA-E4 VGA-E8
VGA In Connector HD-15 Female x 1
VGA Out Connector HD-15 Female x 1
RJ-45 Connector 1 2 4 8
Max. Resolution 2048x1536 60Hz
Cable Distance 180 m (Max.) 300 m (Max.)
Power Adapter (Min.) DC 12V 600mA
Housing Metal Aluminum
Weight 290g 290g 230g 247g 345g
Dimensions (LxWxH) mm 118x75x29 130x83.5x29.5 200x83.5x29.5
