TECHNICAL SPECIFICATIONS
INPUT IMPEDANCE
100k Ohms Line Level
47K Ohms Phono
INPUT SENSITIVITY 126mV for 1V Output, Lone Level
GAIN at 1KHz
18dB Line Level
63dB Phono
OUTPUT IMPEDANCE <10 Ohms
OUTPUT NOISE (RMS)
<0.08mV unweighted, Line Level
<15mV unweighted, Phono
VALVE COMPLIMENT
1 x 6463
1 x 6189
1 x EF80
1 x E80CC
2 x 6X5
2 x OB2
2 x ECL82
FUSE RATINGS
1A anti-surge (110 / 120V supply)
500mA anti-surge (220 / 240V supply)
MAX. POWER CONSUMPTION 81 Watts
TOTAL WEIGHT 30 KG (two units)
TOTAL SHIPPING WEIGHT
(ORIGINAL PACKAGING)
40 KG (two cartons)
UNIT DIMENSIONS
140mm (h) x 440mm (w) x 410mm (d)
140mm (h) x 440mm (w) x 410mm (d)
PACKAGING DIMENSIONS 235mm (h) x 540mm (w) x 510mm (d)
NOTE
Due to Audio Note (UK)’s ongoing
research and development program,
specifications are subject to change
without notice.
