Audio Note M9 Phono User Manual
Page 12
Outputs
The M9 Phono preamplifier provides two Single Ended / RCA outputs,
consisting of two pairs of colour coded RCA / Single Ended sockets.
RED
is for RIGHT channel connection, WHITE is for LEFT channel
connection.
There is also a pair of balanced outputs, consisting of a pair of ‘male’
XLR sockets (see ‘Balanced’ section, below).
CONNECTION OVERVIEW continued…
XLR / BALANCED OUTPUTS,
RIGHT AND LEFT
RCA / SINGLE ENDED
OUTPUTS, LEFT AND RIGHT
BALANCED /
SINGLE ENDED
SWITCH
R
L
R
L
