background image

128-6996A

19 of 28

19

Note: Resistive Circuits, As Well As 4 Wire Polarity Reversal and 5 Wire Alternating 12 Volt
Door Lock Control Circuits
These applications require the use of additional components which may include relays, and or fixed resistors.
Refer to the AUDIOVOX Door Lock Wiring Supplement and or the Audiovox fax back service for information on your
particular vehicle for properly connecting to these types of circuits.

ALARM SELECTABLE FEATURES

NOTE: The Alarm Selectable Features and Remote Start Selectable Features programming steps following are
based on transmitter button 1 being programmed for channel 1 and transmitter button 2 being programmed for
channel 2.
Refer to page 1&2 for alarm selectable features.

RF Programmable Features:
Feature Selection

1 Chirp

2 Chirps

3 Chirps

4 Chirps

Default

1st Door L/UL

1 Sec.

3.5 Sec.

1 Sec L, Dbl. U/L

1 Sec.

2nd Accy Lock

Auto Lock On

Auto Lock Off

Auto Lock Off

3rd Accy. UL

Auto UL Dr.

Auto UL All

Auto UL Off

Auto UL Off

4th Headlights

On Arm

On Disarm

On Both

Off

Both

5th Passive Locks

Passive

Active

Active

6th Passive/Active Arm

Passive Arm

Active Arm

Active Arm

7th Voltage Sense

On

Off

Off

8th Siren/Horn

Siren/Horn

Siren Only

Horn Only

Siren/Horn

9th Horn Chirp

10mS

16mS

30mS

16mS

10th Override Method

Custom Code

Valet

Valet

11th Two Step Unlock

On

Off

Off

12th Chp Delete From Tx On

Off

Off

TIMED START PROGRAM:
The Remote Start unit has the ability to start the vehicle automatically at timed intervals. This feature is useful in
extremely cold climates where starting the engine is the only means to keep the battery charged and fluids warm.
The operator has the option to have the unit start every 2 or 4 hours for a maximum of 48 hours. Factory preset is
to start at 4 hour intervals. To select 2 or 4 hour automatic start timer:

1. Start with the Enable switch (Red Handle) in the "On" Position.
2. Turn the ignition on then off.
3. Within 10 seconds of the key turning off, cycle the enable switch Off, On, Off, On ( 2 times) to select a 2 hour

timed start interval. Cycle the enable switch Off, On, Off, On, Off, On, Off, On (4 times) to select a 4 hour timed
start interval. The lights will flash and the siren will chirp 2X or 4X dependant upon 2 or 4 hour interval setting.

NOTE: Once selected, 2 or 4, this timer interval will remain in memory until it is manually changed. To change,

the above sequence will have to be followed.

TIMED START OPERATION:
To begin the start timer, within 10 seconds of turning off the ignition switch, activate the RF command to start 2
times. (Press button 2 four times). The lights will flash and the siren will chirp 4 times. Indicating timed interval
mode has been initiated. The vehicle will automatically start every 2 or 4 hours as programmed. To cancel the
timed start mode start the vehicle either by RF or by the ignition key.

TEMPERATURE START:
When Temperature Start, feature #11 is selected on, the temperature start mode can be activated from the
transmitter. See owners manual for turning this feature on from the transmitter. Once activated, the unit
will start 1 time if the vehicle temperature reaches "0* " and then will run the allotted time.
