 Technical Specifications
Model WiFi-800
Power Supply AC100-120V, AC 220-240V / 50HZ - 60HZ
Power Consumption 800 W
Output Volume 3000 Cubic Feet / Min
Tank Capacity 0.8 Liter
Fluid Consumption 60 Min. / 0.8 Liter
Weight 4.1 kg
Dimensions (LxWxH) 315 x 128 x 220 mm
Optional Controllers Z-10 On/Off Controller, Z-40 Timer Controller, Z-50
Wireless Controller
First Heat-up Time 1.7 min
 Optional Controllers for WiFi-800

Z-10: 10 meter wired remote controller with 1/4 inch jack plug. The red light indicates that
the unit is receiving power. When the fog machine has reached operating temperature
the green light on this remote controller will light up, indicating that the operator may
begin fog emission by pressing the red button. The green light flashes during fog
machine warm-up and re-heating cycles (approx. 1-2 minutes), and stays ON when the
machine becomes operational. The Z-
10 features the “toggle switch’’ function: press
once for continuous “ON”, press again to release continuous “ON” function

Z-40: 10 meter wired remote controller with 1/4 inch jack plug. Its two knobs allow users
to customize the duration and interval of fog output time. Press the yellow TIMER-button
to activate the timer function. Adjust the interval between each fog emission (within the
range of 10 to 250 seconds) by means of the INTERVAL control knob. Adjust the duration
of each fog emission (within the range of 10 to 120 seconds) by means of the
DURATION control knob. When pressed, the green FOG button overrides all other
control functions and activates maximum output.

Z-50: Wireless remote controller with 1/4 inch jack plug. A remote operation is possible
up to a distance of 50 meters in open area. Keep the red button pressed for fogging.
