Antari M-7 - Manual (Page 11)

11
Technical Specifications
Input voltage 120V 60Hz or 230V 50Hz
Breaker 120V = 15A 250V
230V = 9A 250V
Heater 1550W
Warm-up time 5 min. (approx.)
Coverage volume Height 5 Meters, Width 1 Meter
Max. operating time 8 seconds burst
Fluid tank capacity 2.4 L
Fluid consumption 25 ml/10 sec.
Recommended Fluid Antari FLC Water-based Fluid for the best effect
Control option DMX 512, Manual, Timer, Wireless remote
DMX channels 8 channels
Power connection Neutrik Powercon
DMX data connection 3-pin and 5-pin XLR
Dimension L345 x W193 x H385.7 mm
Dry weight 11.5 kg
