Product Overview

Setting Up

Step 1:

Place the machine on a flat surface and in a suitable large area with at least 50 cm

open space around the machine.

Step 2:

Fill the fluid tank with Antari approved fluid.

Step 3:

Connect the machine to suitable rated power supply.To determine the power

requirement for the machine refer to the label on the machine.

Always connect the machine to a protected circuit and ensure it is properly

grounded to avoid risk of electrocution.

Step 4:

Turn on the machine and allow it to heat up. Heat up takes approximatly 6 mintues.

Once the machine has reached operating temperature, the display will show Ready to Fog.

Now the machine is ready for operation.

Step 5:

To start making fog, press the VOLUME button on the control panel.

Tank Capacity：5 liters

Blue LCD screen, Timer
mode, Volume mode

Neutrik PowerCon

XLR 5-Pin DMX Connector

XLR 3-Pin DMX Connector

Control Options：DMX、W-DMX
