Antari F-7 Smaze - Manual (Page 10)

10
Technical Specifications
Input voltage 110-120V 60Hz or 220-240V 50Hz
Power Consumption Heater: 1500 W
Fan: 72W at 120V 60Hz
74W at 230V 50Hz
Warm-up time 6 minutes (approx.)
Fluid tank capacity 5 Liter
Maximum Fluid consumption Fog Mode: 140 ml per minute
Faze Mode: 28ml per minute
Recommended Fluid Antari FLG water-based fog fluid for the best effect
Control options LCD Menu, DMX 512, Wireless DMX
Adjustable output volume and fan speed
DMX channels 3 channels
Power connection Neutrik PowerCON
DMX data connection 3-pin and 5-pin XLR
Dimension L 710 x W 412 x H 710 mm
Dry weight 52.5kg
