American Diagnostic Corporation (ADC) Diagnostix 3.5v User Manual
Page 11
Electrostatic discharge
(ESD) according to
IEC61000-4-2
± 6 kV contact
discharge
± 8 kV air discharge
± 6 kV contact
discharge
± 8 kV air
discharge
Immunity
Tests
IEC 60601
Test Level
Electromagnetic
Environment Guidelines
Guidelines and manufacturer's declaration - electromagnetic emissions
The Diagnostix
TM
instrument is intended for operation in an electromagnetic environment as specified below.
The customer or the user of the Diagnostix
TM
instrument should ensure that it is used in such an environment.
Note - UT is the alternating supply voltage prior to application of the test level.
Compliance
Level
Floors should be made of wood or
concrete or be covered with
ceramic tiles. If the floor is covered
with a synthetic material, the
relative air humidity must be at
least 30%.
Fast transient electrical
interference/bursts
according to
IEC61000-4-4
± 2 kV for power
lines
± 1 kV for input and
output lines
3 A/m
3 A/m
Not applicable
The quality of the supply voltage
should correspond to that of a
typical business or hospital
environment.
Surges
IEC61000-4-5
± 1 kV voltage
phase-to-phase
± 2 kV voltage
phase-to-earth
Not applicable
The quality of the supply voltage
should correspond to that of a
typical business or hospital
environment.
Voltage dips, short-time
interruptions and
fluctuations in the
supply voltage according
to IEC61000-4-11
Magnetic field at the
mains frequency (50Hz)
according to IEC61000-4-8
<5% UT (>95 % drop
in UT) for 0.5 cycles
40% UT (60 % drop
in UT) for 5 cycles
70 % UT (30 % drop
in UT) for 25 cycles
<5% UT (>95 % drop
in UT) for 5 s
Not applicable
The quality of the supply voltage
should correspond to that of a
typical business or hospital
environment.
If image disturbances occur, the
Diagnostix
TM
instrument may have
to be placed further away from the
sources of mains-frequency
magnetic fields, or magnetic
shielding may have to be installed:
the mains-frequency magnetic
field should be measured at the
intended set-up site in order to
ensure that it is small enough.
