Acura 2004 TL - Owner's Manual - Manual (Page 250)

No. Amps. Circuits Protected
No. Amps. Circuits Protected
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
15 A
7.5 A
15 A
30 A
20 A
15 A
30 A
7.5 A
20 A
40 A
40 A
15 A
30 A
40 A
40 A
40 A
40 A
100 A
50 A
Right Headlight Low Beam
Back Up
IGP
Condenser Fan
Front Fog Light
Daytime Running Light
Radiator Fan Motor
MG Clutch Relay
Horn, Stop
Rear Defroster
Back UP, ACC
Hazard Warning
VSA Pump Motor Relay
VSA Fail Safe Relay
FI ECU
Power Seat
Heater Motor
Battery
IGI Main
1
2
3
4
5
15 A
30 A
7.5 A
10 A
7.5 A
Left Headlight Low Beam
Rear Defroster Coil
Left Headlight High Beam
Small Light
Right Headlight High Beam
U.S. models Canadian models 1 : 2 :
1
2
Fuse Locations
Taking Care of the Unexpected 247
UNDER-HOOD FUSE BOX
