Detecting Unit Real-time Reactivity Monitor
SAAFShield Reading Unit
7.0 Spare Parts List
It is recommended that the following spare parts be stored at the installation site for replacement purposes. Consult with your AAF
representative to determine actual quantities required. Minimum recommended quantities are provided in the table below.
AAF Part Number Description Recommended Spares
392-803-010 Silver Crystal QCM One full replacement set of each type
included in the system.
392-803-011 Gold Crystal QCM One full replacement set of each type
included in the system.
392-803-012 Copper Crystal QCM One full replacement set of each type
included in the system.
To order replacement parts call: 1-800-AAF-2003.
6.0— Connecting to the Reading Unit (RU)
When inserting QCMs for the first time, the RU will automatically
default to the ‘Edit QCM Info’ window and force the user to enter
information regarding QCM parameters. Be prepared to enter this
information when installing a new QCM. See bulletin GPF-3-117.
The Information that will be needed when initializing the Gold, Silver,
and Copper QCMs is:
• Site ID
• Room ID
• Detecting Unit ID
• Detecting Unit installation location information (upstream,
downstream, or in-room)
The Initialization frequency and install date and time will be
automatically recorded by the RU.
