AAF International Type W RotoClone User Manual
Page 12
12
NOTE 1: Shipping weight does not include motor and drive.
NOTE 2: Operating weight includes estimated weight for motor and drive for Arrangements “A” and “D”.
Also includes maximum sludge capacity based on 100 lb. per cubic foot for Arrangement D hopper in the
event of plugged drain line.
Table 2. Shipping and Operating Weight in Pounds
RotoClone
Arrangement A
Arrangement D
Size
Shipping Weight (lbs.)
Operating Weight (lbs.)
Shipping Weight (lbs.)
Operating weight (lbs.)
8
225
425
1,725
2,625
10
360
610
1,810
3,010
12
630
880
2,030
3,380
14
990
1,340
2,790
5,320
16
1,260
1,710
3,760
6,310
20
1,620
2,270
5,420
9,650
24
1,890
2,590
7,190
13,290
27
2,970
3,720
--
--
30
3,870
5,020
--
--
33
4,860
6,360
--
--
36
5,850
7,350
--
--
45
13,500
16,000
--
--
6.0 Weights & Water Usage Tables
Table 1. Normal Water Supply Rates - Type W RotoClones
Size
Arrangement A
Arrangement D
GPM Supplied
GPM Supplied
40 psi
50 psi
60 psi
40 psi
50 psi
60 psi
8
1.1
1.2
1.3
2.1
2.2
2.5
10
1.5
1.6
1.8
3.1
3.4
3.8
12
1.8
2.0
2.2
4.8
5.4
5.9
14
2.3
2.5
2.9
5.3
5.9
6.5
16
3.5
3.9
4.3
7.5
8.4
9.2
20
4.5
5.0
5.5
8.5
9.5
10.4
24
5.5-6.0
6.2-6.7
6.8-7.3
13.5-14.0
15.1-15.6
16.6-17.1
27
7.0-7.5
7.9-8.4
8.7-9.2
----
----
----
30
8.0
8.9
9.8
----
----
----
33
12.0
13.4
14.7
----
----
----
36
14.0-15.0
14.7-15.7
16.7-17.1
----
----
----
45
21.0-22.0
23.6-24.6
25.9-26.9
----
----
----
NOTE 1: Decreased or increased water requirements can be provided by changing nozzle size.
NOTE 2: For air temperatures in excess of 300° F cooling spray nozzles should be provided in inlet duct to compensate for evaporation.
A safe approximation will be 0.2 GPM of additional water per 1000 CFM for each 100° F temperature reduction.
