H9A11 Cabinet Installation/Owner’s Guide 1–1
1
Introduction
1.1 Description
The H9A11 Cabinet (Figure 1-1) is a low-cost, computer-equipment enclosure system that
meets the Electronic Industries Association (EIA) standard 310C and the International
Electrotechnical Commission (IEC) 297 standards and can accommodate fixed or slide-
mounted chassis that fit into a standard 48.26-cm (19-in.) rack.
The cabinet has the following factory installed features:
•
Equipment mounting rails with the EIA universal rail-hole pattern
•
Front trim kit that provides a finished look to the front opening of the cabinet
•
Vented rear lift-off door
•
Nonvented top cover
•
Four nonlocking casters that facilitate the placement of the cabinet. The front two
casters swivel. The rear two casters are fixed.
•
Adjustable leveling feet that are used to stabilize and secure the cabinet at the
installation site.
•
Stabilizer bar that is used to provide cabinet stability when installing or sliding
equipment out of the cabinet.
•
A single-phase H7600-AA (120 Vac), H7600-AB (240 Vac), or H7600-DB (240 Vac)
power distribution units (PDU) --- Each H7600-AA/AB power distribution unit
provides ten (10) ac power outlets and each H7600-DB power distribution unit provides
twelve (12) ac power outlets.
