14
ODSHR Outdoor Woodburning Fireplace
20002264
FP531
surround flush with
finish wall
12/20/01 djt
12"
(305mm)
Max.
12"
(305mm)
min.
*
1¹⁄₂"
12"
(305mm)
Max.
12"
(305mm)
min.
1¹⁄₂"
6"
(159mm)
Min.
1"
Mantel Clearance -
No Noncombustible Facing Material
Combustible Mantel
and Trim
Finished Wall
Header
Standoff
Noncombustible
Material
Surround
Face
Fireplace Opening
* Minimum width from top of sur-
round to bottom of screen rail
Combustible Mantel
and Trim
Finished Wall
Header
Standoff
Noncombustible
Material
Surround
Face
Fireplace Opening
Noncombustible Facing
Material
Must be sealed with non-
combustible material
Ledge Bracket
Finished Wall
2 x 4 Stud
Finished Wall
Must be sealed with
noncombustible material
Fireplace
Front FP531
Fig. 22 Mantel clearances.
MA81
Fig. 23 Combustible mantel clearances.
MA81
rev. 8/5/97
rev. 4/18/01
1���"
Ref.
Combustible materials are
permitted within a shaded area
shown in Figure 25, titled
Minimum Wall Clearances.
�
���
* 12" (305 mm) from top of fireplace opening.
** 6" (154 mm) from top of fireplace opening.
(Noncombustible material must separate the
black face surround of the fireplace and any
combustible mantel material)
