SPECIFICATIONS

CVG-606XL CVG-808XL

Configuration 6x6 8x8
Input Type

6 composite video,
1 sync/video genlock with
sync select switch,
6 stereo audio

8 composite video,
1 sync/video genlock with
sync select switch,
8 stereo audio

Input
Connections

Video: BNC connectors
Audio: RCA connectors

Input Level

Composite video:
1Vpp/75ohm,
Sync/video genlock:
1Vpp/75ohm
Audio: +4dBm/62kohm

Composite video:
1Vpp/75ohm,
Sync/video genlock:
1Vpp/75ohm
Audio: +4dBm/33kohm

Output Type

6 composite video
6 audio stereo

8 composite video
8 audio stereo

Output
Connector

Video: BNC connectors,
Audio: RCA connectors

Output Level Composite video:

1Vpp/75ohm
Audio: +4dBm/50ohm
(27Vpp max.)

Composite video:
1Vpp/75ohm
Audio: +4dBm/50ohm
(24Vpp max.)

Video S/N
Ratio

74dB 74dB

Audio S/N
Ratio

88dB unweighted, (1Vpp) 88dB unweighted, (1Vpp)

Video
Bandwidth

Exceeding 200MHz

Audio
Bandwidth

Exceeding 100kHz

Differential
Gain

0.05% 0.05%

Differential
Phase

0.03Deg. 0.03Deg.

K-Factor

<0.05%

Non Linearity <0.1% <0.1%
Video
Crosstalk

<-50dB @ 5MHz

THD

0.016% (1V, 1KHz)

2nd Harmonic 0.004% 0.004%
Switch System Vertical interval

Vertical interval

Control Type Manual, RS-232 or

RS-485

Manual, RS-232 or RS-485

Power
Consumption

11VA 11VA

Weight

3.4 kg (7.5lbs.) Approx.

3.5 kg (7.8lbs.) Approx.

Dimensions
(H x W x D)

19" x 7" x 2U

Power Source 230VAC, 50/60 Hz,

(115VAC, U.S.A.)

230VAC, 50/60 Hz,
(115VAC, U.S.A.)

HOW DO I GET STARTED?

The fastest way to get started is to take your time and do everything right the first time. Taking 15 minutes to
read the manual may save you a few hours later. You don’t even have to read the whole manual - if a certain
section doesn’t apply to you, you don’t have to spend your time reading it.
