TABLE OF HEX CODES FOR THE MASTER CVG-808xl
The table below shows the “HEX” codes for switching the master CVG-808xl.
The table is also valid for the CVG-606xl if the last two rows and columns are ignored.
OUT 1 OUT 2 OUT 3 OUT 4 OUT 5 OUT 6 OUT 7 OUT 8
IN 1
01
81
81
81 01
81
82
81 01
81
83
81 01
81
84
81 01
81
85
81 01
81
86
81 01
81
87
81 01
81
88
81
IN 2
01
82
81
81 01
82
82
81 01
82
83
81 01
82
84
81 01
82
85
81 01
82
86
81 01
82
87
81 01
82
88
81
IN 3
01
83
81
81 01
83
82
81 01
83
83
81 01
83
84
81 01
83
85
81 01
83
86
81 01
83
87
81 01
83
88
81
IN 4
01
84
81
81 01
84
82
81 01
84
83
81 01
84
84
81 01
84
85
81 01
84
86
81 01
84
87
81 01
84
88
81
IN 5
01
85
81
81 01
85
82
81 01
85
83
81 01
85
84
81 01
85
85
81 01
85
86
81 01
85
87
81 01
85
88
81
IN 6
01
86
81
81 01
86
82
81 01
86
83
81 01
86
84
81 01
86
85
81 01
86
86
81 01
86
87
81 01
86
88
81
IN 7
01
87
81
81 01
87
82
81 01
87
83
81 01
87
84
81 01
87
85
81 01
87
86
81 01
87
87
81 01
87
88
81
IN 8
01
88
81
81 01
88
82
81 01
88
83
81 01
88
84
81 01
88
85
81 01
88
86
81 01
88
87
81 01
88
88
81
