FRONT OPEN VIEW
ITEM P/N
QTY DESCRIPTION
1 RX67A
1 TOP COVER, CABINET
2 SF79A 2 SIDE
PANELS
3 CD313 1 HOPPER
ASS'Y
4 M705A
1 DOOR LATCH
5 RV57Q
1 TROUGHT DRAWER ASS'Y
6 CD272
1 STEAM DEFLECTOR
7 CD67A
1 SOCKET F/ MIXING BOWL
8 L299A
1 RINSE SWITCH
9 CD275
1 DISPENSE CHAMBER [8mm dia.]
10 CD321
1 WHIPPER CHAMBER
11
CD322
M848A
CD66A
CD89A
1
1
2
1
BASE MOUNT CLOSED F/ WHIP. CHAMBER
PLUG F/ BASE MOUNT
GROMMETS
MOUNTING BAR
12 L069A 1 POWER
SWITCH
13
M849A
K682A
1
1
COFFEE SPOUT, WHITE TEFLON 1.75” L
HOT WATER SPOUT [1.5”L X 4”L]
14 NA91A 1 CAUTION
LABEL
15 SF84A 1 GRILL
16 SF83A 1 TRAY
17 SF23A
1 FACIA BOTTOM CAP
18 C002A
1 HEATER LIGHT
19 CH93A 1 DOOR
HARNESS
20 K618A
1 HIDDEN HINGES [1 SET]
21
NF17A
NF58A
N978A
1
1
1
START UP PROCEDURE INSIDE DOOR
PROGRAMMING INSTRUCTIONS
CLEANING AND SANITIZING INSTRUCTIONS
22 SF19Q
1 DOOR FRAME ASS'Y
23
SF21A
SF22A
L576A
L557A
1
1
3
2
INSIDE DOOR PANEL
KNOBS COVER
TEACH ME TIMERS
POTENTIOMETERS
24 L567A
1 HEATER SWITCH
25 Ni70A
1 SWITCH PANEL LABEL
26 L574A
1 STOP SWITCH RED
27 L457A
1 HOT WATER SWITCH AMBER
28 L455A
2 DISPENSE SWITCH GREEN
RIGHT SIDE OPEN VIEW
ITEM P/N
QTY DESCRIPTION
1
L556A 2
SPEED CONTROL BOARD F/AUGER MOTOR
2 CD151
2 AUGER
MOTOR
3 CD56A
1 BLOWER
LEFT SIDE OPEN VIEW
ITEM P/N
QTY DESCRIPTION
1 L566A 1 LEVEL
CONTROL
BOARD
2 B129A 2 RELAYS,
SAFETY
3 CF29A 2 TRANSFORMERS
4
CD257
1
WATER INLET VALVE
5
M830A
1
HOSE - inlet valve to tank .375 Id x 9"L
6
M829A
1
HOSE - drain .375 IDx12"L
7 K525A 1 ELBOW
8
M832A
1
HOSE - Disp. Valve, Nozzle .375 Id x 11"L
9
M831A
1
HOSE - Disp. Valve–Chamber .375 Id x3.5"L
10
L467A
2
DISPENSE VALVE [1-Product, 1-Hot Water]
11 M494A
M461A
1
6
GROMMET PLUG [ F/ TESTING ]
GROMMET [ 0.466 DIA ]
12 SG06Q
M600A
1
1
TANK BODY ASS’Y
SPLICED GASKET,
CUT FROM 21.75” TO 21”
10
