INSTALLATION Ш (JOIST MOUNTING - II)
Joist situation:
Spacing В is
10
1/2 inches (266 mm) to
111/2 inches (292 mm)
inches on joists
. в ,
Гг
r\
Jojsts
/ '
1. If the spacing В is 10 1/2 inches (266 mm) to 11 1/2
inches (292 mm) on joists, please follow the
installation step as below.
2. Secure 4 long screws (ST 4.2X20) at flange of frame. (Fig. 13)
3. Follow steps 4 to 11 of installation I (page 8, page 9,
page 10) to complete the installation work.
MAINTENANCE
A
warning
Disconnect power source before working on unit.
A
caution
о
о
о
Routine maintenance must be done every year.
Never use gasoline, benzene, thinner or any other
such chemicals for cleaning the ventilating fan.
Do not immerse motor in water when cleaning.
Do not soak resin parts in water over 140°F (60°C).
1. Clean grille. (Don't put into hot water. Use non-abrasive
kitchen detergent, wipe dry with clean cloth)(Fig.14)
2. The grille should be dry after cleaning.
3. Remove dust and dirt from fan body using a vacuum
cleaner. (Fig. 15)
4. Using a cloth dampened with kitchen detergent, remove
any dirt from fan body. Wipe dry with clean cloth. (Fig.16)
5. Replace grille.
6
. When replacing the light kit grille, please purchase new
light kit grille from our representative. (Model number of
light kit grille is FV-LKG08VKME3 for FV-08VKME3 and
FV-LKG08VKSE3 for FV-08VKSE3) (Fig.17).
