Kimber Model 8400 - Manual (Page 12)

12
1. Barrel*
2. Recoil Lug*
3. Receiver*
4. Bolt Stop
5. Bolt Stop Screw
6. Bolt Stop Spring
7. Ejector
8. Ejector Pin
9. Ejector Spring
10. Trigger Fixing Screw
11. Takedown Screw -
Front
12. Takedown Screw -
Rear
13. Bolt*
14. Bolt Handle
15. Extractor
16. Extractor Clip
17. Cocking Piece
Housing
18. Cocking Piece
19. Cocking Piece Screw
20. Firing Pin
21. Firing Pin Safety
22. Safety
23. Cocking Piece
Housing Plunger
24. Safety Plunger Spring
25. Cocking Piece
Housing Plunger
26. Magazine Well
27. Trigger Guard
28. Floor Plate
29. Latch
30. Trap Door Pin
31. Latch Spring
32. Trap Door
33. Magazine Follower
34. Magazine Spring
35. Stock***
36. Butt Plate***
37. Sling Swivel (2)
38. Grip Cap
39. Grip Cap Screw
40. Trigger Housing
41. Sear
42. Sear Pivot Pin
43. Sear Spring
44. Trigger Pressure
Spring
45. Trigger Overtravel
Screw
46. Sear Contact
Adjustment Screw
47. Securing Pin
48. Trigger Adjustment
Nut
49. Trigger
50. Trigger Pivot Pin
51. Trigger Spring
52. Scope Base Plug (4)
53. Scope Base, Front**
54. Scope Base, Rear**
55. Scope Base Screw
(4)**
56. Scope Clamping
Screw (2)**
57. Safety Fixing Pin
58. Trigger Guard
Screw (3)
* Supplied as a Factory
Assembly Only
** Supplied only as
Trigger Assembly
***Supplied as a Stock
Assembly Only
Parts List
18
23
24
25
22 21
52
55
54
56
6
4
49
40
46
42
40
48
44
51
47
43
8
19
7
9
5
47
17
57
45
50
10
Model 8400 - Exploded V
