Connecting External Speakers
1
This jukebox is equipped with external speaker
outputs.
2
The speaker jacks for external speakers are
located on the back of the jukebox. Beside the
speaker jacks is a switch labeled (int./ext./mix).
When using external speakers, this switch must
be switched to the ext. or mix position. The ext.
position will allow only the external speakers to
play. The mix position will allow both the external
and internal speakers to play.
3
If you decide not to use the external speakers,
be sure the switch is on int. or the internal
speakers will not work.
Note: External speakers are not included with
the jukebox.
13
Specification
Frequency Range : FM 87.5 - 108.5 mHz
: AM 525 - 1710 kHz
Power Source : AC 120V ~ 60 Hz
Power Consumption : 130 W
Antennas : External 300 Ohm connection
for AM/FM antenna
Speaker : 6 ½” Dynamic type x 2
: 2 ½” Tweeter type x 2
* DESIGN AND SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE. DO NOT REMOVE COVER.
PILOT LAMPS SOLDERED IN PLACE. NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL. 1
To turn on the lights, press the Light button (3)
on the front of the unit.
2
Adjust the Stage Light Switch to Stop or Run(25)
to make the Eternity Lights constant or in motion.
3
A special note about Bubble Tubes.
It takes several minutes for the bubble tubes to
begin bubbling after the jukebox has been turned
on.Normally they start bubbling within 10 or 15
minutes.If the bubbles don't start in that length
of time you can very gently tap on the bottom
of the tube with your fingernail to start the
bubbling.
Your jukebox is equipped with four "Bubble
Tubes". Bubble Tubes have been used in
jukeboxes since the 1940s. Their bright bubbling
appearance creates an enchanting display which
adds color and movement to your Crosley
Jukebox. The tubes are filled with a liquid
that "boils" or bubbles at approximately 100
degrees. Each of the four tubes has a small
resistor at the base of the tube that provides the
heat for the tube. Small crystals in the bottom
of the tube serve to concentrate the heat and
cause the bubbles. The tubes are very safe in
their sealed environment, however care should
be taken not to jar or bend the tubes. If broken
you should not handle the fluid and you should
make every attempt to clean up the liquid as
soon as possible. Like the neon in your Crosley
jukebox, bubble tubes should never wear out.
The "air" at the top of each tube is not air, but
a vacuum. The amount of vacuum may be
greater or smaller at various times due to
atmospheric conditions and ambient temperature.
The tubes must have the vacuum at the top so
that they do not shatter when heated.
Although some of the vacuum is hidden by the
chrome pieces on the jukebox it is considered
normal to have a small amount of vacuum or
air space showing.
NOTE: When you unpack your Jukebox you will find the CD magazine, remote control,the external
antenna wire, and catalog with warranty information enclosed. The antenna will be in a small plastic bag
packed next to the box with the CD magazine. It consists of a small black wire about 3 feet long.
One end has a metal connector. Insert this end into the 75 ohm antenna plug on the back of the Jukebox.
The exclamation point
within an equilateral
triangle is intended to
alert user to the
presence of important
operating and
maintenance (servicing)
instruction in the
literature accompanying
the appliance.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
The lighting flash with
arrowhead symbol, within
an equilateral triangle, is
intended to alert user to
the presence of uninsulated
"dangerous voltage" within
the product's enclosure
that may be of sufficient
magnitude to constitute
risk of electric shock
to persons.
CAUTION: TO REDUCE
THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE
COVER (OR BACK). NO
USER - SERVICEABLE
PARTS INSIDE. REFER
SERVICING TO QUALIFIED
SERVICE PERSONNEL.
General
Lights / Bubble Tubes
