9 | Dimensions and connections
SV
DV Suction line
Discharge line see technical data, Chapter 8
A Connection suction side, not lockable
7/16“ UNF
A1 Connection suction side, lockable
7/16“ UNF
A2 Connection suction side, not lockable
1/8“ NPTF
B Connection discharge side, not lockable
7/16“ UNF
B1 Connection discharge side, lockable
7/16“ UNF
C Connection oil pressure safety switch OIL
1/8“ NPTF
D Connection oil pressure safety switch LP
1/4“ NPTF
E Connection oil pressure gauge
1/8“ NPTF
F Oil drain M22 x 1,5
G Opt. connection for oil sump heating 1) M22 x 1,5
H Oil charge plug
1/4“ NPTF
K Sightglass 1 1/8“- 18 UNEF
L Connection thermal protection thermostat
1/8“ NPTF
M Oil strainer M22 x 1,5
SV1 Opt. connection for suction line valve --
1) = Only possible ex factory
