2 | product description – GEA Bock HG6 R134a User Manual
Page 6
6
D
GB
F
E
96181-01.2015-DGbFEI
2| Product description
• Semi-hermetic four-cylinder reciprocating compressor with suction-gas cooled drive motor.
• Flange-mounted drive motor on the compressor case.
• Application range: normal refrigerating and air-conditioning with R134a.
Fig. 1
2.1 Short description
Dimension and connection values can be found in Chapter 9
Name plate
Valve plate
Cylinder cover
Terminal box
Transport eyelet
Discharge
shut-off valve
Oil pump
Suction
shut-off valve
Oil sight glass
Drive section
Motor section
1
2
3
4
5
6
7
8
9
10
11
12
13
