2 | product description – GEA Bock HG22Р CO2 User Manual
Page 7
D
GB
F
E
7
96019-02.2015-DGbFEI
2| Product description
2.2 Name plate (example)
2.3 Type key (example)
¹
)
HG - Hermetic Gas-Cooled (suction gas-cooled)
²
)
X
- Ester oil charge
³
)
Additional declaration for Pluscom compressors
Fig. 3
1
Type designation
6
Voltage, circuit, frequency
2
Machine number
7
Nominal rotation speed
3
maximum operating current
8
Displacement
4
Starting current (rotor blocked)
9
Voltage, circuit, frequency
5
ND (LP): max. permissible operating
10 Nominal rotation speed
pressure
(g)
Low pressure side
11 Displacement
HD (HP): max. permissible operating
12 Oil type filled at the factory
pressure
(g)
High pressure side
13 Terminal box protection type
Observe the limits of application
Electrical accessories can change
diagrams!
the IP protection class!
50 Hz
}
60 Hz
}
/
HG
2
2 P 125- 4 CO
2
X
CO
2
Version
Number of poles
Swept volume
³
)
Numbers of cylinders
Size
Oil charge ²
)
Series ¹
)
1
2
3
4
5
13
12
7
11
6
10
8
9
40/55
AS33567A001
C85E
20,9/12,1A
Δ: 121A Y: 70A
GEA Bock GmbH
72636 Frickenhausen, Germany
