more susceptible to interference from radio wave sources.
Note: There is no easy way to evaluate their effect on the
overall immunity of your powered Scooter.
5. Report all incidents of unintended movement or brake
release to your supplier, noting if there is a radio wave
source nearby. He will then be able to diagnose your
Scooter to eliminate any possible Scooter component
failure. Please note a charge may be made for this service.
Your Scooter has been tested to the following standards
with reference to EN12184. Emissions EN50022(B),
Immunity IEC1000-4-3, E.S.D. IEC801-2
Note: All figures, speeds, measurements and capacities
shown in this manual are approximate and do not
constitute specifications. Our policy is one of continual
improvement. We reserve the right to alter, without notice,
any weights, measurements or other technical data shown
in this manual. If you require specific accurate data,
please contact your authorised dealer.
Enjoy your Scooter Enjoy your Scooter
ADVISORY SAFETY NOTICE
Warning: Radio wave sources may affect Scooter control.
Your powered Scooter is designed to operate in appropriate
environments, however radio wave sources
such as radio or TV broadcasting stations, amateur (Ham)
radio transmitters, two-way radios and
cellular portable telephones can affect powered motorised
Scooters.
The following warnings listed below should reduce the
chance of unintended brake release or
uncontrolled powered Scooter movement.
1. Do not turn on hand held personal communication
devices such as citizen ban (CB) radios and cellular
phones, while your Scooter is turned on.
2. Be aware of nearby transmitters such as radio or TV
stations, and try to avoid coming into close contact
with them.
3. If unintended movement or brake release should occur,
turn your Scooter OFF as quickly as it is safe to do so.
4. Be aware that adding accessories or components or
modifying your Scooter may make it
Warning:
SCOOTER SPARE PARTS
Power Key Switch
Horn Button
Horn
Battery Meter
Top Control Board (P.C.B.)
Potentiometer Spring
Variable Resistor 20k (min-max speed)
Black Knob (min-max speed)
Charger Socket Assembly
Front Basket
Front Wheel Bearing
Anti-Tipping Wheel
Self Lock Nut Front/Rear Wheel M12
Arm Rest Pad
Arm Tighten Knob
Battery Cable
Power Key
The following list of components can be purchased from your local
Agent from whom you purchased your Scooter. Quoting model code Your Scooter is an electro-mechanical machine. Some of its
consumable components will need replacing due to normal wear
and tear.
PAEI-0405
PM90-0100
PM00-0303
PP07-0102
PU00-1202
PP14-0101
PP00-0200
PK90-0401
PM90-0900
PM01-0100
PKEI-0103
PKEI-0603
PKEI-0700
PAEI-0300-B1
PM02-0200
PAEI-0100-MO
PP01-0500
39
DESCRIPTION PART number DESCRIPTION PART number
