SYSTEM PARAMETERS
The System Parameters are where various system setups are done, this includes calibration of the CV
scaling along with renaming the outputs for easier reference.
EDIT NAME
Each of the 24 outputs can be renamed to something that resembles your system for easier use. If you
find the outputs are used for different things all the time, then it may pay to leave them with their default names,
the above example has re-labelled output 1 as A100 Rack, whilst another output may be MS-404, this
method saves having to remember which output jack the device is connected to.
Use the menu knob to scroll along the characters in the name, and use the Value knob to edit the
characters.
TUNE MODE
This selects between 1 volt per octave or Hertz per volt scaling. 1 volt per octave is used for most
modular systems including the Doepfer A-100, Roland System 100m & System 700, Moog modulars,
Digisound modular, Emu and Arp systems etc, this also includes mono synths such instruments as Roland ,
Moog , ARP, Octave (like the Cat and Kitten), Korg Mono/Poly, Sequential Pro-One, Oberheim (SEMs
and OB1) and many others.
The Hertz per volt system was used by Korg (except the Mono/Poly) and Yamaha.
TUNE NOTE #1
This sets the reference Midi note number for calibration of the CV. The range is from 0 to 127.
<- - - E - > : O u t p u t 0 1
Sy s t e m P a r a m e t e r
Ed i t : O u t p u t 0 1
Na m e : A 1 0 0 r a c k
Tu n e : O u t p u t 0 1
Mo d e : V o l t / O k t a v e
Tu n e : O u t p u t 0 1
No t e # 1 : 0 0 0
