CRANKSHAFT PULLEY 177-3308 69
CYLINDER HEAD AS-
SEMBLY 231-2072 19
CYLINDER HEAD COV-
ER 238-1330 73
CYLINDER HEAD GAS-
KET (111147560) 19
231-2073 19
DAMPER 153-6393 35, 35
DIPSTICK (198416820) 49
DIPSTICK TUBE 229-5150 49
DOWEL (030500512) 11
(030500612) 17, 17, 17
(030500616) 11
(030501025) 11
(030509018) 31
END CAP (064209053) 29
EXHAUST MANIFOLD 183-4332 63
EXHAUST MANIFOLD
GASKET 153-6860 63
EXHAUST VALVE 153-5555 19
FAN 183-3539 43
FANBELT (080109049) 45
FILLER 205-7713 77
FLYWHEEL 153-6864 57
FRONT OIL SEAL 153-7978 25
FUEL INJECTION PIPE -
NO 1 CYL 231-7702 35
231-7703 35
231-7704 35
FUEL INJECTION PUMP (131017940) 33
FUEL INJ PUMP RETURN
PIPE (068209026) 37
Description Part No. Page
GASKET 154-2716 37
205-4727 33, 33
219-4669 47
231-3014 73
231-3020 73
GAUZE 153-5939 73
GEAR - IDLER/OIL PUMP 153-7984 31
GLOW PLUG 231-2836 39, 39, 39
GUDGEON PIN 153-5540 13
HOSE 154-1823 41
HOUSING JOINT 231-7858 41
INLET VALVE 231-2070 19
INSERT 230-9126 19
JOINT 153-6494 69
153-7920 75
KEY (030509020) 17
LAMP 197-8547 83
LEVER 153-5577 21
153-5579 21
183-3570 25
183-4030 65
231-3821 25
238-1266 25
LIFT PUMP 176-7712 55
MAIN BEARING KIT 231-2800 17
METRIC BOLT 217-5860 73
NUT (020109176) 29
(020109177) 29
(020700008) 25
(020800018) 69
