Tools required for installation parts – Chief Manufacturing XSM Series User Manual
Page 5
Installation Instructions
XSM/XTM Series
5
TOOLS REQUIRED FOR INSTALLATION
PARTS
7/32" (5.5mm) Wood Stud
#2
5/16" (7.9mm) Concrete
Custom
XSM2XXX/
XTM2XXX
Hardware
[Included with
XSM2XXX/XTM2XXX
Models Only]
J11 (6)
M5
A (1)
B (1)
C (1)
E (1)
F (1)
G (1)
H (4)
J (1) [Used on XSMU/XTMU Models Only]
J1 (6)
M6x16mm
J2 (6)
M6x25mm
J3 (6)
M8x20mm
J4 (6)
M8x30mm
J5 (4)
M8x50mm
J6 (6)
M10x40mm
J7 (6)
M10x50mm
J8 (6) J9 (6)
M6
M8
J10 (6)
1.00x.400x.75"
.750x.323x.250"
J12 (1)
J13 (1)
M6
(XTM Only)
(XSM Only)
K (1)
K1 (4)
5/16"
K2 (4)
5/16"
K3 (4)
5/16" x 2-1/2"
L (1)
