8
in serious personal injury or death.
Fuel Shut Off Valve
The fuel shut off valve is located under the seat and
it is strapped onto the fuel tank. It controls fuel to the
engine. To turn fuel off, turn knob so indicator is down.
To turn fuel on, turn knob to the up position. See
Figure 5.
Adjustable Seat Lever
The adjustable seat lever is located beneath the driver’s
seat on the front side and it is used to move the seat
forward and backward. See Figure 6.
Slide the lever to the left and push the seat forward or
back to the desired position. Release
the lever so that it locks the seat in
place.
WARNING: Make sure seat is in
locked position prior to operation and do not try to
adjust the seat position while operating the vehicle.
Cargo Box
The cargo box is raised by a gas spring. Manually remove
the contents of the cargo box before lifting the cargo box.
Push the release latch down and lift up the cargo box.
Once the cargo box is in the raised position, access to
the engine is possible. If equipped with a electrical lift, the
cargo box can be raised to dump cargo. See Figure 7.
IMPORTANT: Do not exceed the vehicle’s Total Load
Capacity of 1,200 lb., which includes driver, passenger,
accessories, and cargo. Do not exceed 800 lbs. in the
cargo box.
Tailgate
The tailgate can be hinged at the top or the bottom
depending on how you release the holding pins. If you
Make sure seat is
in locked position
prior to operation
and do not try
to adjust the
seat position
while operating
the vehicle.
IMPORTANT:
Do not exceed the
vehicle’s Total Load
Capacity of 1,200
lb., which includes
driver, passenger,
accessories, and
cargo. Do not
exceed 800 lb. in
the cargo box.
3
Know Your
Utility Vehicle
WARNING
Figure 6
Figure 7
Figure 8
Figure 5
Fuel Shut-off Valve
