8
SPECIFICATIONS
Engine: 20HP Kohler (44”), 23HP Kohler (50”) & 23HP Kawasaki (60”)
Type: Vertical air cooled V-Twin
Air Cleaner: Paper element
Lube System: Pressurized with oil filter, drain valve with hose
Starter: 12-volt electric
Traction Drive: Engine to variable-speed integrated hydraulic pump and wheel motors
on each drive wheel
Cutter Deck;Drive: 44”, 50” & 60” belt driven
Clutch: Electric
Deck Lift: Foot Pedal with pin lock for height adjustment at 1/4” increments
Cutting Height: 1-1/2" to 4"
No. of Blades 3, belt-driven, power take-off from engine
Controls: Engine ignition and start switch; throttle; choke; left and right steering
levers; electric blade clutch switch; parking brake; mower deck lift
Parking Brake: Mechanical linkage attached to the brake handle
Front Caster Wheels: 11 x 4.00 - 5 for 44” & 50”, 11 x 6.00-5 for 60”
Tire Pressure: 8-10 psi rear, 20-25 psi front caster
Drive Wheels: 18 x 8.50-5 for 44”, 18 x 9.50-8 for 50” & 20 x 10.00-10 for 60”
Frame: Structural steel, all welded construction
Seat: Adjustable seat. 4" Adjustment, w/ arm rests
Fuel Tank: One 5 gallon with shut off valve
Ground Speed: 0-7 MPH forward & 0-3 MPH reverse for 44” & 50”, 0-8 MPH forward
& 0-3.5 MPH reverse for 60”
Instrumentation: Hour meter
Net Weight: 602 LBS w/44”, 618 lbs w/50” & 689 lbs w/60”
