Parts List
8
1 710-0751 HH Cap Screw 1/4-20 x .620
2 736-0270 Bell Washer .265 x .75 x .062
3 748-0318 Wheel Ratchet
4 720-0223 Grip
5 732-0803A Spring Lever
6 738-0529 Shoulder Nut
7 750-0515 Spacer .51 x .70 x .38
8 741-0978 Hex Sleeve Bearing
9 782-0565 Single Lever Control Arm
10 714-0104 Hairpin Clip
11 736-0286 Bowed Washer
12 611-0064 Front Axle Assembly
13 741-0492A Block Bushing
14 710-1242 Hex Screw 1.4 x 1
15 731-0982A Hubcap
16 738-0102 Shoulder Screw .498x1.445x3/8-16
17 736-0504 Wave Washer .510 x .750 x .017
18 734-2008A Front Wheel 8 x 2.125 Idle BB Zrk
19 736-0105 Bell Washer .375 x .870 x .063
20 741-0324A Hex Flange Bearing
21 736-0369 Flat Washer .508 x 1 x .020
22 750-0151 Spacer .550 x .755 x 1.1
23 682-3052 Handle Bracket Assy RH
682-3053 Handle Bracket Assy LH
24 710-1348 AB Screw 1/4-14 x .50
25 10622B Plastic Ratchet Spring
26 738-0137A Shoulder Screw .340x.285x1/4-20
27 748-0381 PAWL RH
748-0188B PAWL LH
28 16855 Ratchet PAWL Plate
29 734-2010 Rear Wheel 9 x 2.125 Rwd PM
30 712-0414 Weld Nut
31 710-1315 TT Screw 3/8-16 x 1.25
32 750-0807 Spacer .385 x .625 x .700
33 732-0832 Torsion Spring RH
34 711-0835 Clevis Pin .500 x 4.62
35 710-1652 TT Screw 1/4-20 x .625
36 782-0568 Lift Assist Spring Bracket
37 714-0474 Cotter Pin
38 731-1901A Trailshield
39 732-0842 Trailshield Wire
40 682-7526 Axle Assembly Transmission
41 710-0604A TT Screw 5/16-18 x .625
42 618-0263A Transmission
43 741-0522 Hex Flange Bearing
44 713-0453 Chain
45 638-0012 Axle Assembly RR
46 682-7528 Chain Cover Assembly
47 750-1056 Shoulder Spacer .385 x .715
48 725-0157 Cable Tie
49 682-0531 RR Pivot Arm Assembly
