17

Parts List

To order replacement

parts call our Customer

Dealer Referral Line at

1-877-282-8684 or visit

www.cubcadet.com to
locate a dealer in your

area.

1

647-04008

Lever Assembly

2

710-1270

Machine Screw, 1/4-20 x 1.310

3

712-04063

Flange Lock Nut, 5/16-18

4

726-0240

Cable Tie

5

746-0557

Control Cable, 47-inch

6

710-0654A

TT Screw, 3/8-16 x 1.00

7

782-0078B

21-inch Deck

8

736-1836

Front Axle Cover

9

710-1242

HL Screw, 5/16-14 x .750

10 756-04161

Upper Half Pulley

11 756-04160

Key Half Pulley

12 736-0250

Flat Washer, 1 x 1.75 x .107

13 736-04173

Spring Washer 1.005x1.825x.048

14 731-1828

Rear Baffle

15 748-04082

Blade Adapter

16 742-0741

21-inch Mulching Blade

17 710-1257

HH Cap Screw, 3/8-24 x 2.50

18 736-0524B

Bell Blade Spacer

19 631-0071

Grass Bag Cover Assembly

20 712-04064

Flange Lock Nut 1/4-20

21 710-0653

TT Screw 1/4-20 x .375

22 710-0969

HL Screw #12-16 x 1

23 747-0937

Grass Bag Frame

24 747-0939

Grass Bag Pivot Rod

25 726-0106

Cap Speed Nut

26 664-0121

Grass Bag Assembly

8

IMPORTANT: For a proper

working machine, use

Factory Approved Parts.

V-BELTS are specially

designed to engage

and disengage safely.

A substitute (non-OEM)

V-Belt can be dangerous

by not disengaging

completely.

27 731-1832

Side Discharge Chute

28 747-04451

Belt Keeper Rod

29 754-0460

V-Belt

30 750-04438A Sleeve Spacer
31 731-1833A

Mulch Cover

32 712-0397

Wing Nut

33 726-0233

Push Nut

34 710-0134

Carriage Screw 1/4-20 x .62

35 731-1713B

Top Discharge Chute

36 747-0965

Chute Door Pivot Rod

37 732-0819

Torsion Spring

38 731-1874

Top Discharge Door Chute

39 726-0111

Push Cap

40 631-0066

Top Discharge Chute Assembly

41 714-0104

Cotter Pin

42 712-0397

Wing Nut

43 710-0703

Carriage Screw 1/4-20 x .75

44 749-0907B

Lower Handle

45 747-0940A

Grass Bag Support Rod

46 720-04072

Star Knob

47 710-1174

Carriage Bolt 5/16-18 x 2

48 712-0324

Hex Lock Nut 1/4-20

49 746-0883

ERS Housing

50 746-0711B

51-inch Cable

51 749-0439D

Upper Handle

52 753-0833

Drive Control Assembly

G

E N

U I N

E

FA

CTO

RY PA

RT

S
