20
9. SPECIFICATIONS
STANDARD FUNCTION
System NTSC / PAL Video System and Video Loss Auto Detection
Codec MPEG4-SP ASF File Format
Record Frame Rate
1, 2, … , Maximum fps selectable
Maximum:
30 fps@320x240 / 12 fps@640x480
Record Quality Low / Medium / High
Recording Date/Time Overlay with Video Images in ASF File
Input From Built-in Camera
Video
Cam
Output 1 CH Composite Video Line Out
Sampling Rate 44.1 KHz
Mic High Sensitivity Microfone
Codec G.726/ 32 kbps
Input From Built-in Microphone
Audio
Output 1 CH Audio Line Out
Resolution SONY CCD 480TVL High Resolution
Lens 3.7mm Pinhole Lens
Audio Device Microphone
Storage Media SD Card (FAT16/ up to 32GB) MAX FILES: 16384 FILES
Serial Port USB 1.1 (Read-Only)
Recording Mode Manual / Schedule ( Alarm / Motion Detection / Continue)
Motion Detection Setting Multiple Blocks and adjustable sensitivity
Event Search Function Property and first image of selected file is displayed
Playback Function Play/Fast Forward/Fast Rewind/Pause/Step Forward/Step Backward
Playback Speed x1/ x2/ x4/ x8/ x16/ x32
Power Supply AC110V
Dimensions 140mm (L) x 75mm (W) x 27mm(H)
Operating Environment 30%~80% RH, 5°C ~ 45°C (41°F ~ 113°F)
Storage Environment 30%~90% RH, 0°C ~ 50°C (32°F ~ 122°F)
(Note: Design and Specifications are subject to change without notice.)
Min. Illumination 0.1 LUX
