Operation Manual for Intelligent Speed Dome Camera
Scan system 15.625KHz(H) 50Hz(V)
horizontal 480 horizontal
Signal-to-Noise > 48db
shutter 1/3～1/10000sec
Camera
function
Sensitivity 0.01～1Lux(F1.6)
Zoom rate 18x optical 12x digital
iris Auto / manual
Lens
parameter
focus Auto / manual
Pan speed 0～15°/s (Fixed 15rad/s for constant dome)
Tilt speed 0～15°/s (Fixed 15rad/s for constant dome)
Preset 64presets(max)
Dome
Function
Auto cruise At best 6 cruises
Ⅵ. Troubleshooting
Problem Probable cause Solution
Power supply fault Replace
Bad connection of the
power
Make correction On power no action
Transformer damaged Replace
Mechanical failure Repair
Camera incline Reinstall
On power cannot
self-check have image but
have motor noise
Power supply not enough Replace
Video signal fault Reinstall
Bad connection of the video Press to full connect
Self-check ok, but have
no image
Camera damaged Replace
RS485 Bus bad connection Check the RS485 connection
Dome id setting is wrong Reselect
Self-check ok but cannot
control
Protocol setting is wrong Reset and on power again
Bad connection of the video Press to full connect
Vague image
Power supply not enough Replace
Self check error On power again
Bad connection of control Press to full connect On power cannot control
Bad control of matrix On power again
