4 Other
4.1 LAN and WAN configuration
♦ LAN automatically search
Run DVS Client, Click , the video server in the local LAN will appear in the device
list. Only PC and video server in same network segment can connect.
If there are no device in the device list, make sure the following question:
① If DVS is already powered?
② If DVS and PC have been normal connected? If yes, the light will be long bright or
flashing.
③ If PC has firewall working? If yes, should do it again after closing the firewall.
♦ WAN manually search
If users want to login in another subnet, the device can not automatically be searched. The
video device should be manually added as the following steps:
① Register DDNS services from a DDNS service provider. After applications a domain
name will be assigned, and an account number and password will be obtained.
② Click mouse right key in device list up item, choose 【 Property】→【DDNS】 set your
domain info ,please see 3.3.2 for details.
③ When Internet IP is changed. The device will automatically tell DDNS server its new
Internet IP.
④ Users only input domain in the network browser can run Client.
4.2 Application for DDNS
Normally users use dynamic IP address in the internet. User can use a static hostname instead
of a dynamic IP address to monitor Lan device image. In this way, user should register a domain
name and obtain a password. The device supports www.3322.org and www.dyndns.org , users can
login it and register the domain, after doing it, set your domain info as 3.3.2 for details.
4.3 Router configuration
Routers must be set to enable a PC TCP connecting to the device. Routers use port number to
decide which device request is allowed, this function is port transmitting or virtual services.
