– 3 –
2.0 CONTENTS
Your Pocket-Strobe portable stroboscope comes with the following items:
■ PK2X, PK2X-OT, PK2X-AC Stroboscope
■ Universal AC-Adapter/Charger (100–240 VAC)
■ External Triggering Jack
■ Carrying Case
■ Traceable Calibration Certificate
■ Instruction Manual
– 22 –
16.0 S PECIFICATIONS
Flash Range 30 – 12,500 FPM
Flash Brightness 1200 Lux (8"/20cm distance @ 4500 fpm)
Accuracy ± 0.01% over entire range +1 LSD ± 0.04 Hz
Resolution ± 1 FPM over entire range
Display 5-digit LCD
Display Update 0.5 seconds
Flash Energy 170 mJ
Flash Duration < 9 µs
Flash Tube Life 200 million flashes (at 6,000 fpm)
Flash Color Temp 6,000K – 6500K
External Trigger 0-5 volt, DTL/TTL compatible 1/8" jack
Optional Trigger Signal 0-5 volt, DTL/TTL compatible 1/8" jack
Output (PK2X-OT Only)
Operating Time Battery, 2 hours
AC-Power , continuous
Battery Type Lithium Ion (Li-Ion)
Battery Charger AC Power Required , 100-240 VAC, 50/60 Hz
DC-Output , 9 VDC @ 2000 mA max
Charging Time, 4-5 hours
Overcharge Protection Yes
CE Certification Yes
Weight 0.9 lbs (415 grams) including battery
Housing Material High Impact ABS Plastic
Reflector Material Aluminum
Tripod Mount 1/4-20, female insert
Operating Temp. 32 to 104° F (0 to 40° C)
Dimensions 9–3/4" x 2–3/4" x 1–3/4" (240 x 65 x 40 mm)
Warranty 1 year
