Clarke ® Operator's Manual - Encore S30/L30 Page -5-
SPECIFICATIONS:
Model Encore L30
Machine Power Supply 24 Volt D.C., 24 Volt D.C.,
(4) 6V 250 AH Deep Cycle Batteries or (2) 6V 195 AH Deep Cycle Batteries or
(4) 6V 330 AH Deep Cycle Batteries (4) 6V 250 AH Deep Cycle Batteries or
(4) 6V 330 AH Deep Cycle Batteries
Pad or Brush Gimbal Style 3-Lug Driver Style
2 per machine
Traverse
0.5 hp (0.4 kW) Transaxle Brush Assist
Traverse Forward Speed Variable to 250 ft./min (76 m/min) Not Applicable
Traverse Reverse Speed Variable to 190 ft./min. (58 m/min) Not Applicable
Battery Protection Low Voltage
Motor Vacuum 3/4 HP, 3 stage, Acoustical High Efficient Tangential
Solution Tank 20 Gallons (76 liters)
Solution Level Calibrated level indicator on rear of machine
Recovery Tank 20 Gallons (76 liters)
Recovery Full Indicator Electric Shut-Off
Parabolic Squeegee Swing type with breakaway feature, No tool operation feature
39 inches (99 cm) hard width with 41 inches (104 cm) flex blade width.
Squeegee Operation Reverse direction on floor and 3 - position manual lever style operation
Cleaning Swath 30 inch (76 cm) adjustable head
Motor, Brush 0.75 HP (0,56 kW) 5.2:1 High Torque Gear Box
Brush / Pad Size (2) 15 inch (38 cm)
Brush Speed 200 RPM
Brush Pressure 0-150 lbs. / 0-68 kg.
Brush Solution Retention Fiber Bristles
Drive Wheels (2) 8 in. x 2 in. (20 cm x 5 cm) Neoprene tread
Caster Dual 4 in. x 2 in. (10 cm x 5 cm)
Charger 24 V D.C., 25 Amp, 115/60 or 24 V D.C., 25 Amp, 230/50
Grade Cleaning 5 Degree (6%) 2%
Length 56 inches (142 cm)
Width 28 inches (71 cm)
Height 43 inches (109 cm)
Weight 871 lb / 395 kg
Line of Sigh (from Operator
Height): 68 inches (173 cm)
7.5 feet (2.3 m)
Warranty Machine 3 Years, Polydur tanks- 8 years
Batteries- 18 months, pro-rated
Noise 71 dBA 71 dBA
Vibration < 2.5 m/s 2 <2.5 m/s 2
Introduction & Machine Specifications
Introduction & Machine Specifications
Clarke’s newly designed Encore S30 and L30 automatic scrubbers are efficient and superior floor
cleaning machines. The Encore uses two brushes to scrub a path 30 inches wide. A squeegee wipes
the floor while the vacuum motor removes the dirty solution from the floor - all in one pass.
The Encore S30 comes complete with either four - 6 volt batteries or two - 12 volt batteries, one battery
charger, either two brushes or two pad drivers, and one operator’s manual.
The Encore L30 comes complete with four - 6 volt batteries, one battery charger, either two brushes or
two pad drivers, and one operator’s manual.
Encore S30
