24 s
PeciFicAtioNs
Specifications
A-Net I/O - Pro64 2 EtherCon RJ45 connectors
Network Sample
Rates, Pro64
44.1/48kHz; 88.2/96kHz; 176.4/192kHz ±
(see below)
Sample Rate Range,
Pro64
1x 44.1/48kHz, 39.7kHz to 52kHz
2x 88.2/96kHz, 79.4kHz to 104kHz
4x 176.4/192kHz, 158.8kHz to 208kHz
A-Net Out - Pro16 4 EtherCon RJ45 connectors
Pro16 Outputs Channels 1‑16
Channels 17‑32
Channels 33‑48
Channels 49‑64
Bit Depth 24‑bits
Network Latency Total latency is less than 1ms (measured
from analog in to analog out)
Cable Length, Cat-5e,
Pro64 network
Maximum 400 feet (120 meters);
Use Unshielded Twisted Pair (UTP) cable
Cable Length, Cat-5e,
Pro16 network
Maximum 500 feet (150 meters);
Use Unshielded Twisted Pair (UTP) cable
Power Supply 100‑240VAC 50‑60Hz, 24W
Internal switching power supply;
IEC connector
Fuse F4AL
Dimensions 1U; 19”w x 8”d x 1.75”h
482.6 x 203 x 44 mm
Weight 5.5 pounds;
2.49 kg
All Aviom products are designed and manufactured in the USA.
