Parallel A-Net Routing
Connecting A‑Net devices in parallel involves the addition of an A‑Net
distributor. Any number of A‑Net distributors can be added, creating an
infinite number of digital splits.
Using an A-Net Distributor
A-Net
Distributor
A-Net In
A-Net Out
A-Net In
AN-16/o AN-16/o AN-16/o A-16R A-16 II
A variety of A-Net compatible components are shown connected in parallel
to an A-16D or A-16D Pro A-Net Distributor.
The A‑Net output from the A‑16D or A‑16D Pro A‑Net Distributor in the
diagram above is connected to each Pro16 A‑Net compatible device’s A‑Net
input with a Cat‑5e cable. Removing one A‑Net device has no effect on the
other A‑Net outputs being used.
When configuring a Pro16 system, modules can be connected in any order;
simply connect A‑Net Out to A‑Net In as needed.
