10 Hanging The TV
I II
III IV
Present the yellow Hangers
(on the back of the TV) to the
guide recess on the Wall
Brackets. Slide down and across
into place. Ensure both yellow
Hangers are fully engaged.
If cables from the TV prevent
the TV resting against the wall
then an alternative hanger
configuration will be required
(See Section 11).
TV must be parallel to wall. Use
spacers / stand-offs as shown.
Guide
Recess
If required you can adjust
the level of your TV by moving
your TV from side to side.
Removing the TV
This is a two person job. To remove the TV reverse the movements as shown above.
