1 Boxed Parts
A
- x2
Wall Bracket
B
- x2
Hanger (Yellow)
C
- x2
Stand-off
Template
M4 45mm M4 25mm
F
1 - x4
M4 16mm
E
1 - x4
M4 Adaptor
You will not need all these parts, so expect there to be some left over depending upon the
specification of your TV.
TV Fixings: Parts go on the back of the TV (specification of your TV will determine which
ones you require - see section 11).
F
2 - x4
F
3 - x4
M5 45mm M5 25mm
F
4 - x4
M5 16mm
E
2 - x4
M5 Adaptor
F
5 - x4
F
6 - x4
M6 45mm M6 25mm
F
7 - x4
M6 16mm
E
3 - x4
M6 Adaptor
F
8 - x4
F
9 - x4
M8 45mm M8 25mm
F
10 - x4
M8 16mm
D
1 - x12
Spacer
F
11 - x4
F
12 - x4
Wall Fixings: Parts to attach to the wall (type of wall will determine which fixings you
require).
H
- x6
Long Wall Plug
J
- x6
Long Screw
K
- x2
Metal Stud Screw
M
- x6
Screw
No.14 x 105mm No.14 x 70mm
L
- x6
Wall Plug
I
- x12
G
- x6
Wall fixing
Included Tools
O
18mm Wood Drill
N
3mm Hex Key
P
1
P
2
Lock Nut
No.12 x 25mm
Spacer (Red)
D
2 - x4
Q
Level
