aW5800x
Line-of-sight :: 5.8 GHz
Thank you for your purchase of the
AW5800x point-to-point wireless Ethernet
bridge.
If you have any questions when configuring
your AvaLAN system, please send an e-mail
to [email protected].
For a live technician, please call technical
support at (650) 384-0000.
For advanced installation information,
please visit www.avalanwireless.com.
Operational summary
User’s Manual
PaGe 2 Technical support :: (650) 384.0000 www.avalanwireless.com
The AW5800x replaces costly wiring with a wireless Ethernet bridge that can enable remote Wi-Fi access points, Ethernet pan/tilt/zoom
security cameras, VoIP phones, or Internet kiosks. AvaLAN’s product offers the ideal combination of price, range, data rate, security,
interference avoidance, quality-of-service, and ease-of-use.
The AW5800x is the best solution when:
— a Broadband Ethernet drop will cost too much or is impractical to install
— guaranteed DSL-rate throughput is required (kiosks/Wi-Fi access points/PTZ cameras)
— guaranteed latency for voice or video is required (PTZ cameras/VoIP)
— 900 MHz and 2.4 GHz are saturated due to interference (airport/campus/mall/city)
— ultra-low current consumption is required (1 Watt/solar powered systems)
Features include:
— high RF output power and exceptional receive sensitivity provide ultra-long-range wireless Ethernet bridging up to 30 miles
— does not interfere with Wi-Fi networks
— highest Quality of Service (QoS) available — synchronous point-to-point protocol enables applications that require low data
— latency and jitter (surveillance video and VoIP)
— 128 bit encrypted with dynamic private keys
— Solar ready low power consumption < 1.8 Watt typical usage
— Simple plug and play — pre-configured as matched pairs with no user programming required
— 58 non-overlapping channels with frequency agility to avoid interference
— operates in the 5.725-5.850 GHz band and does not require an FCC license to operate or install
n
n
n
n
n
n
n
n
n
n
n
n
n
aW5800x Kit
Long-range 5.8 GHz wireless outdoor Ethernet
bridge. Kit includes:
Requires antennae: Use with AW5-5800 or AW23-5800 — both FCC
approved
— (2) AW5800x outdoor radios
— (2) 110 VAC to 12 VDC power adapters
— (2) Power over Ethernet injectors
