Leipzig-S/SK User Manual

Analogue Solutions | EG1 & EG2 - ENEVELOPE GENERATORS

21

SUSTAIN

Once the Attack and Decay stages have passed, Sustain sets the level that the EG will
hold its output at for as long as a key is held down.

RELEASE

Once the key is released, this sets the time take for the signal to fade to zero.

LED

The LED gives a rough approximation of output level.

MIDI TRIG SWITCH.

The EGs can be triggered from MIDI or the sequencer. When this switch is down it can
be triggered from MIDI.
