The RTR System Management Environment
The Command Server Process executes commands both locally
and across nodes. Commands that can be executed at the RTR
COMSERV include:
• START RTR
• CREATE/MODIFY JOURNAL
• SHOW LINK/FACILITY/SERVER/CLIENT (ACP must be
running)
• Application programmer commands (for testing and
demonstration)
The RTR system management environment is illustrated in
Figure 5–1.
Figure 5–1 RTR System Management Environment
LKG-11216-98WI
FE
RTRACP
RTRD
RTR
COMSERV
RTR CLI
RTRD
TR
RTRACP
RTRD
RTR
COMSERV
RTR
COMSERV
BE
RTRACP
RTR CLI
Management
Station
Running
Browser
Software
The RTR Environment 5–3
