CONTROL HEAD INSTALLATION TEMPLATE
5
-1/4”
2
-5/8”
5
-7/8”
6
-1
/4”
1/2”
1/8”
2
-7/8”
2
-1/2”
This inner area to be removed.
CAUTION: Please note that top and bottom edges only provide 1/8” overlap. Cut carefully.
