usually 25 ampere) or ampere-hour capacity (a measure of how many amperes a battery can deliver for a
specified length of time).

Example – Reserve capacity: a battery with a reserve capacity of 180 minutes can deliver 25 ampere for 180
minutes before it is completely discharged.

Example – Ampere-hour capacity: a battery with an ampere-hour capacity of 100 ampere-hours can deliver
5 ampere for 20 hours before it is completely discharged.

To determine the battery ampere-hour capacity:

1) Determine how many watts each piece of AC equipment (TV, light bulbs, etc) consumes. This can

normally be found on the product label. If only the current draw is given, multiply the current draw by
115 to get the watt consumption.

2) Estimate the time (in hours) that each piece of equipment will be running between battery charging

cycles.

3) Calculate the total watt-hours of energy consumption (power in Watts x operating time in hours)

using the average power consumption and the total estimated running time (in hours). Power x
Operating Time = Watt-Hours.

4) Divide the watt-hours by 10 to determine how many battery (12 volt) ampere-hours will be

consumed.

4.2 T

YPICAL

P

OWER

C

ONSUMPTION

Appliance

Watts

Appliance

Watts

Stereo

200

Microwave - 1000 W

1000

Table Fan

200

AC (5,000 BTU)

700

TV-VCR

250

Computer

300

Small Refrigerator

350

Hair Dryer

1000

Hand Drill - 1/2"

600

Coffee Maker

1200

Light Bulb - 100 W

100

Blender

400

4.3 W

IRE

G

AUGE

R

EFERENCE

4.3.1

Ampacity Table

Load Amperage – Power @ 12VDC

10A

120W

20A

240W

30A

360W

40A

480W

50A

600W

60A

720W

70A

840W

80A

960W

100A

1200W

120A

1440W

160A

1920W

200A

2400W

250A

3000W

Ca

b

le

L

en

g

th

(f

ee

t)

2

16AWG 16AWG 14AWG 12AWG 10AWG 8AWG 8AWG 6AWG 4AWG

2AWG

2AWG

2/0AWG

3/0AWG

4

16AWG 16AWG 14AWG 12AWG 10AWG 8AWG 6AWG 6AWG 4AWG

2AWG

1AWG

2/0AWG

4/0AWG

6

16AWG 14AWG 12AWG 10AWG 8AWG 6AWG 6AWG 4AWG 2AWG

2AWG

1/0AWG

3/0AWG

4/0AWG

8

16AWG 14AWG 12AWG 10AWG 8AWG 6AWG 6AWG 4AWG 2AWG

2AWG

1/0AWG

3/0AWG

4/0AWG

10

16AWG 14AWG 12AWG 10AWG 8AWG 6AWG 6AWG 4AWG 2AWG

2AWG

1/0AWG

3/0AWG

4/0AWG

12

14AWG 14AWG 12AWG 10AWG 8AWG 6AWG 6AWG 4AWG 2AWG

2AWG

1/0AWG

3/0AWG

4/0AWG

16

14AWG 12AWG 12AWG 10AWG 8AWG 6AWG 6AWG

4AWG

2AWG

2AWG

1/0AWG

3/0AWG

4/0AWG

20

14AWG 12AWG 10AWG 8AWG 6AWG 6AWG

4AWG

4AWG

2AWG

2AWG

2/0AWG

4/0AWG

4/0AWG

24

12AWG 12AWG 10AWG 8AWG 6AWG

4AWG

4AWG

2AWG

1AWG

1AWG

2/0AWG

4/0AWG

4/0AWG

28

12AWG 10AWG 8AWG 8AWG

6AWG

4AWG

4AWG

2AWG

1AWG

1AWG

2/0AWG

4/0AWG

4/0AWG

33

10AWG 10AWG 8AWG 6AWG

4AWG

4AWG

4AWG

2AWG

1AWG

1AWG

2/0AWG

4/0AWG

4/0AWG

42

10AWG 8AWG 6AWG 6AWG

4AWG

4AWG

2AWG

1AWG

1/0AWG

1/0AWG

3/0AWG

4/0AWG
