CONTENTS | OPERATION
GENERAL INFORMATION
1. General Information
Read this entire manual. Failure to follow all the guides, instructions
and rules could cause personal injury or property damage.
Improper installation, adjustment, alteration, service and use of
this unit can result in serious injury.
This unit must be installed by a licensed electrician and plumber. The
installation must comply with all national, state and local plumbing
and electric codes. Proper installation is the responsibility of the
installer. Failure to comply with the installation and operating
instructions or improper use voids the warranty.
Save these instructions for future reference. Installer should leave
these instructions with the consumer.
If you have any questions regarding the installation, use or
operation of this water heater, or if you need any additional
installation manuals, please call our technical service line at 800-
582-8423 (USA and Canada only). If you are calling from outside
the USA or Canada, please call USA 413-247-3380 and we will refer
you to a qualifi ed Stiebel Eltron service representative in your area.
OPERATION
!
THIS IS THE SAFETY ALERT SYMBOL. IT IS USED TO ALERT
YOU TO POTENTIAL PERSONAL INJURY HAZARD. OBEY
ALL SAFETY MESSAGES THAT FOLLOW THIS SYMBOL TO AVOID
POSSIBLE INJURY OR DEATH.
The chapter Operation is intended for homeowners, heating
contractors, plumbers and electricians.
The chapter Installation is intended for heating contractors,
plumbers and electricians only.
1.1 Symbol key
1.1.1 Layout of safety information
DANGER Electric shock
Before any work on the appliance,
disconnect all poles from the power
supply.
e e e e e e e e e e e e e e e e e e e e e po p p p po po po po p po p p p p p p p p p wer
1 3
4
2
1 Symbol (see 1.1.2 "Symbols")
2 Keyword (see 1.1.3 "Keywords")
3 Designations (see 1.1.2 "Symbols")
4 Information text
1.1.2 Symbols
Symbol Description
Injury
Electrocution
Burns or scalding
! Other situations
1.1.3 Keywords
KEYWORD
DANGER The keyword DANGER indicates information that
must be observed, otherwise serious injury or
death will result.
WARNING The keyword WARNING indicates information that
must be observed, otherwise serious injury or
death may result.
CAUTION The keyword CAUTION indicates information that
must be observed, otherwise relatively serious or
light injuries may result.
1. General Information ____________________________________ 2
1.1 Symbol key ______________________________________________ 2
2. Safety precautions ______________________________________ 3
3. Register your product __________________________________ 3
4. Temperature increase above ambient water
temperature _____________________________________________ 4
5. Technical drawings _____________________________________ 4
6. Overview ________________________________________________ 6
6.1 Figure legend ___________________________________________ 6
6.2 General description _____________________________________ 6
6.3 Important information before supplying power to
unit _______________________________________________________ 6
6.4 Hot water output ________________________________________ 7
6.5 Incorrect use ____________________________________________ 7
6.6 First steps to be taken in the event of malfunction ___ 7
6.7 Maintenance and care __________________________________ 7
7. Operating and installation instructions _______________ 7
7.1 Mounting the unit _______________________________________ 7
7.2 Plumbing connections __________________________________ 7
7.3 Electrical connection ____________________________________ 8
8. Initial start-up __________________________________________ 8
9. Water heater hand over ________________________________ 8
10. Normal maintenance ___________________________________ 8
11. Technical data ___________________________________________ 9
12. Troubleshooting _________________________________________ 9
13. Spare parts _____________________________________________ 10
14. Warranty _______________________________________________ 10
