Adjustment
Adjustment of the automatic-start position
This adjustment is preset at the factory. If play starts from the middle of a tune, or the stylus descends outside the disc circumference, make the
necessary adjustment.
1. Clamp the tonearm. 2. Remove the dust cover. 3. Adjust to the desired automatic
tion.
4. Check to be sure the automatic-start position is correct.
Perform steps 3-7 on the opposite page (Automatic play) to check the position.
5. Attach the dust cover.
Replacement
Replacement of the stylus
If noise is heard from new discs, the stylus is probably worn.
Replace it with a new one.
•Stylus life................................................................. approx. 1000 hours
•New stylus ...............................................................................EPS-24CS
Ф Remove the tape on side of cartridge.
@ Pullout
the old stylus.
@ Insert the
new stylus.
/ No gap!
Don't touch stylus tip!
Maintenance
Replacement of the cartridge
The plug-in type of cartridge ITIPI is already designed to match this
unit in every respect: weight, correct stylus pressure, stylus tip
position, center of gravity, etc. This means that there's no longer
any need for troublesome connection of lead wires or adjustment of
the stylus pressure.
To clean dust from the stylus
Use a soft brush or similar material to gently remove the dust.
Thoroughly clean your discs occasionally with a high-quality disc
cleaner.
^^Carefully.. .in the arrow direction!
Maintanance of external surfaces
To clean this unit, use a soft, dry cloth.
If the surfaces are extremely dirty, use a soft cloth, dipped into a
soap-and-water solution or a weak detergent solution.
Wring the cloth well before wiping the unit.
Wipe once again with a soft, dry cloth.
Never use alcohol, paint thinner, benzine, nor a chemically treated
cloth to clean this unit.
Such chemicals may damage the finish of your unit.
- 5 -
