QuickSpecs
Compaq Evo Workstation W6000
DA-10840 North America — Version 22 — March 18, 2002 26
Technical Specifications
48X CD-ROM Drive Disk Applicable Disk CD-ROM (Mode 1 and 2), CD-R/W, CD-R
Photo CD (Single and Multi-session), Mixed Mode (Audio
and Data combined), CDI Ready, CD-XA Ready, CD TEXT,
CD EXTRA
Capacity 540 MB (Mode 1, 12 cm)
650 MB (Mode 2, 12 cm)
Rotational Speed 8750 maximum
Diameter 4.7 in, 3.15 in/12 cm, 8 cm
Center Hole 0.6 in/15 mm diameter
Thickness 0.05 in/1.2 mm
Track Pitch 1.6 µm
Block Size Mode 1 2,048 bytes
Mode 2 2,340, 2,336 bytes
CD-DA 2,352 bytes
CD-XA 2,328 bytes
Interface IDE
Access Times (typical) Random < 100 ms
Full-Stroke < 150 ms
Audio Output Level Line-Out 0.7 VRMS
Data Transfer Rate Sustained 150 KB/s (1X, using audio disc)
Variable 3,000 to 7,200 KB/s
Cache Buffer 128 KB minimum
Start-up Time (typical) < 7 s
Stop Time < 4 s
Operating Conditions Temperature 41° to 113°F/5° to 45°C
Humidity 10% to 80%
Dimensions (HxWxD, maximum) 1.7 x 5.9 x 8.19 in/4.29 x 15 x 20.8 cm
Weight 2.65 lbs/1.2 kg
