Adjustments

Adjustment menu

Contrast

Adjust the screen contrast to match the brightness level in the room.

Pressing the [U key toggles between brightness and contrast.

Direct operation]

Even if the menu screen does not appear, the contrast can be adjusted by pressing

the Э or e key. If the & and ►! keys are pressed at the same time, the

maximum level (100) will be set.

Brightness

! Adjust the brightness to match the brightness level in the room so that the level

will be easy to see.

Pressing the Ш key toggles between contrast and brightness.
Note: It the Э and в keys are pressed at the same time on the Brightness

____

adjustment screen, the standard level (50) will be set.

Щ Size & Pos.

! Press the

[Ц

key to select the zoom

horizontal position

horizontal size

vertical

position / vertical size adjustments.

Press the Ш key to save the adjustment.

Zoom

! Both the horizontal and vertical size of the image can be adjusted at the same

time: however, the aspect ratio cannot be changed.

Press the Э key to make the image smaller, the key to make it larger.

D H. Position !

The horizontal position of the image can be adjusted.

Press the S key to move it to the left, the key to move it to the right.

H H. Size

The horizontal size of the image can be adjusted.

Press the Э key to make the image smaller, the È key to make it larger.

Note: Setting the image in the center of the screen to start will make the

adjustment easier.

V. Position

! The vertical position of the image can be adjusted.

Press the Э key to make it downward, the ►j key to move it upward.

m V. Size !

The vertical size of the image can be adjusted.

Press the Э key to make the image smaller, the key to make it larger.
Note: Setting the image in the center of the screen to start will make the

adjustment easier.

i/ (I

Geometry

: Press the

key to select the vertical pincushion

side pincushion balance

trapezoid / parallelogram / Geometry 2 adjustments.

___

Press the QJ key to save the adjustment.

nr V. Pincushion !

The image can be adjusted for barrel distortion.

Press the 5« key to decrease the Pin / Barrel distortion of the image,

the K key to increase it.

ГТ Side Pin. Bal. !

The image can be adjusted for the side pincushion balance to the left

and right. Press the key to expand to the left of the image, the €

key to expand it to the right,

Trapezoid

!The image can be adjusted for trapezoidal distortion.

Press the 3 key to make the top edge narrower, the key to make the

___

bottom edge narrower.

/~~7

Parallelogram

!The image can be adjusted for parallelogram distortion.

Press the Э key to collapse the parallelogram to the left, the ►] key

to collapse it to the right.

► ► Geometry 2 ;

Press the

key to change the sub OSD screen.

Press the \J\ key to select the Top Corner I Bottom Corner / S-Curve 1 /

S-Curve 2 adjustments.

Top Corner

! The image can be adjusted for vertical pincushion distortion in the

top corner.

Bottom Corner

The image can be adjusted for vertical pincushion distortion in
the bottom corner.

S-Curve 1

S-Curve 2

The image can be adjusted for vertical pincushion distortion in the S-
Curvel.

> I

The image can be adjusted for vertical pincushion distortion in the S-
