TPS400 and TPS800 DXF Data Output Page
3
dxf3DH
This option creates a 3D DXF file of the measured points, which are placed in a layer
led Point, with 3D co-ordinates as a dot. The Height is placed in the layer Height. cal
.
Height
dxf3DPH
This option creates a 3D DXF file of the measured points, which are placed in a layer
called Point, with 3D co-ordinates as a dot. The Point Number and Height are placed
in the layer Height. A space is placed in front of the Point Number and another
ween the Point Number and the Height. bet
.
PointId Height
dxf2DH
This option creates a 2D DXF file of the measured points, which are placed in a layer
led Point, with 2D co-ordinates as a dot. The Height is placed in the layer Height. cal
.
Height
dxf2DPH
This option creates a 2D DXF file of the measured points, which are placed in a layer
called Point, with 2D co-ordinates as a dot. The Point Number and Height are placed
in the layer Height. A space is placed in front of the Point Number and another
ween the Point Number and the Height. bet
.
PointId Height
dxfPCENH
This option creates a 3D DXF file of the measured points, which are placed in a layer
called Point, using a cross symbol. The Point Numbers, Codes, Eastings, Northings
and Height are placed in the layer Code. A space is placed in front of the Point
Number and commas separate the remaining fields.
+
PointId,Code,Eastings,Northings,Height
